INFRASTRUCTURE
The Department has sufficient number of well equipped class rooms, laboratories with state of the art software and equipment, seminar hall, drawing hall and Department library.
- UG Class Rooms: 3
- PG Class Rooms: 2
- Exclusive U.G. & P.G. Air conditioned computer laboratory with 72 computers.
- Air-conditioned Seminar Hall
- 9 well equiped Laboratories
- Dean / HoD office and Faculty rooms / cabins
- Teaching aids like smart board, OHP, explanatory models & charts, etc
LABORATORY FACILITIES
Strength of Materials Laboratory
Geotechnical Engineering Laboratory
Concrete and Highway Laboratory
Construction Materials and Technology Laboratory
Environmental Engineering Laboratory
Computer Laboratory
Survey Laboratory
Structural Engineering Laboratory
GIS Laboratory
STRENGTH OF MATERIAL LABORATORY
Strength of Materials Laboratory (319 sq.m.)
- Compression Testing Machine (100T & 300T Capacity)
- Universal Testing Machine (40T Capacity)
- Servo controlled Digital Universal Testing Machine (100T Capacity)
- Impact Testing Machine (Izod and Charpy Methods)
- Hardness Testing Machine (Rockwell and Brinell Type)
- Torsion Testing Machine
- Spring Testing Machine (Open and Close coil springs)
- Wood Testing Machine
Wood Testing Machine
Universal Testing Machine 40T
GEOTECHNICAL ENGINEERING LABORATORY
Geotechnical Engineering Laboratory (92 sq.m.)
- Sieve Shaker and Hydrometer
- Relative Density test apparatus
- Atterberg’s Limit apparatus
- Field density test apparatus (Core cutter and Sand replacement)
- Permeability test apparatus (Constant head and Falling head)
- Standard Proctor Compaction test apparatus
- Consolidometer
- Shear strength test apparatus (Direct Shear, UCC, Vane Shear and Triaxial)
- Standard Penetration test apparatus with all accessories
- CBR Test apparatus with all accessories
- Plate Load Bearing test apparatus with all accessories
CONCRETE AND HIGHWAY LABORATORY
Concrete and Highway Laboratory (131 sq.m.)
- Slump Cone Apparatus
- Compaction Factor Test Apparatus
- Flow Table Apparatus
- Vee Bee Consistometer
- Compression Testing Machine (100T & 300T Capacity)
- Universal Testing Machine (40T Capacity)
- Digital Compressometer
- Digital Extensometer
- Impact Testing Machine
- Crushing Strength Apparatus
- Loss Angles Apparatus
- Deval Attrition Test Apparatus
- Bitumen/Tar Standard Penetrometer
- Bitumen Ductility Testing Machine
- Tar Viscometer
- Ring and Ball Apparatus – Bitumen
- Pensky Marten Flash and Fire Point Test Apparatus
- Marshall’s Stability Test Apparatus
- Bitumen Extractor/Centrifuge Extractor
- Plate/Table Vibrator (50cmx50cm)
- Needle Vibrator
- Cement Mortar Cube Vibrating Machine
CONSTRUCTION MATERIAL LABORATORY
Construction Materials and Technology Laboratory (500 sq. m.)
- Vicat Apparatus, Sieves and Sieve Shaker, Lechatlier’s Apparatus
- Pyconometer, IS Sieves, Buoyancy Balance, Flakiness Gauge, Elongation Gauge
- Slump Cone, Compaction Factor Apparatus, Vee Bee Consistometer,
- Flow Table – Concrete and Cement Mortar
- 500 kNDigital Compression Testing Machine
- L Box, U Box, V Funnel
- Concrete Permeability Test Apparatus
- Hot Air Oven, Digital Scale
- Non Destructive Testing Equipment – Rebound Hammer, Profometer, Resipod (Resistivity Meter), Half Cell Potential Apparatus, Core Cutter
- Potentiostat – Electrochemical Work Station for Corrosion Analysis
- Sophisticated 8 Channel NI Data Acquisition System – Load and Strain Measurement
- Rapid Chloride Ion Permeability Apparatus
- Acceleration Corrosion Test Apparatus
- Coating Thickness Guage
- Ion Conductivity Meter – Chloride Analyser
- 5.5 digit Multimeter
- Sophisticated DC Power Supply unit
Testing of Specimens
Flow Table Test
ENVIRONMENTAL ENGINEERING LABORATORY
Environmental Engineering Laboratory (120 sq.m.)
- pH Meter
- Turbidity Meter
- Hot Air oven (0 to 200°C)
- Muffle Furnace (0 to 600°C)
- Jar Test apparatus
- Flame Photo Meter
- Atomic Absorption Spectro Photometer
- UV-VIS Double Beam Spectrophotometer
- Peristaltic pump
- Water and soil Analysis Kit
- BOD Incubator
- COD Digester
- Indoor Air Quality Sampler
COMPUTER LABORATORY
Computer Laboratory (156 sq.m.)
- Computer System – Core i5 3rd Gen Processor, 16 GB RAM – 19 nos.
- Computer System – AMD Veriton Processor, 8 GB RAM – 20 nos.
- Computer System – Core 2 duo Processor, 4 GB RAM – 32 nos.
- Computer System – Wipro i5 Processor, 4 GB RAM – 1 no.
- Primavera P6, Perpetual License – 10 users
- Cost X, Licensed – 30 users
- Auto CAD, Educational License Version
SURVEY LABORATORY
Survey Laboratory (102 sq.m.)
- Total Station (Trimble Focus) – 3 nos
- Total Station (Kolida) -2 nos
- Auto level – 5nos
- Transit Vernier theodolite – 20 nos
- GPS Q Mini Serial – 1 no
- Dumpy level – 5 nos.
Experiment using Theodolite
STRUCTURAL ENGINEERING LABORATORY
Structural Engineering Laboratory (253 sq.m.)
- FIE Universal Testing Machine, Model UTES-100
- Rod Type linear potentiometer(100 ohms Spring Return)
- Horizontal shake table with Experimental Models
- 5T Electrically operated hydraullic power pack
- VEE-Bee Consistometer, Compaction Factor Apparatus
- Concrete Permeability Apparatus with Compressometer
- 10T Capacity Loading Frame
- 5T Capacity Servo – hydraulic activator with a standard two column fixed loading frame
- AIM-378-DG-S2 Digital Lateral Extensometer Combined Compressometer & Extensometer
- Data Logging & Signal Conditioning system with 8 channels
- AIM -390-Air Permeability Apparatus
- Round Drum semi automatic concrete mixer 100kg capacity
- AIM-404 Shrinkage Bar Mould with 4 Compartments
- 100KN Capacity Strain Controlled Universal Testing Machine (100KN)
- Self Consolidating Concrete Apparatus
- Concrete Crack Microscope
- 50T Load Cell – Compression type with 10m Cable
- 100mm Displacement LVDT Sensor with 5m Cable
- 20 Channel Data Logger
- Data Acquisition System with Vibration Analyses Software
- Computerized Displacement & Strain Recording Equipment
- AC LVDT with Magnetic Stand (0 to 10mm & 0 to 50mm)
- String Potentiometer 0 to 50mm
- Displacement Sensor (0-10mm & 0 – 50mm) Spring loaded
- Pundit Lab Ultrasonic Testing Instrument
Mortar Compactor
Universal testing machine 100 T
GIS & REMOTE SENSING
GIS Laboratory (100 sq.m)
- Bentley Academic Bundle Select (5 users)
- Quantum GIS (QGIS) – Educational Version
